Technical Parameters :
Model | Automatic Dual-head Crimping Single Terminal Insertion Machine |
Wire Size Range | 0.1 – 2.0 mm² |
Processing Length | 60 – 950 mm (customizable) |
Length Accuracy | ≤300 mm: ±0.5 mm ≥300 mm: ±(0.2% × L ±1 mm) |
Production Capacity | 1100 – 1300 pcs/hour (based on 150 mm wire) |
Crimping Force | Servo 2 Ton |
tripping Length | 1 – 10 mm |
Stripping Accuracy | ±0.2mm |
Housing Pitch | 0.8-10mm |
Inspection System | CCD Vision with AI Deep Learning |
Applicable Tooling | European / Japanese (OTP) |
Dimensions (MM) | 1750W×990L×1700H(without protrusions) |
